Call agents from code

You can invoke Agent Builder agents from your applications using the LangGraph SDK or the REST API. Agent Builder agents run on Agent Server, so you can use the same API methods as any other LangSmith deployment. The REST API lets you call your agent from any language or platform that supports HTTP requests.

Prerequisites

A LangSmith account with an Agent Builder agent
A Personal Access Token (PAT) for authentication
(SDK only) The LangGraph SDK installed:

pip install langgraph-sdk python-dotenv

Authentication

To authenticate with your agent’s Agent Builder deployment, provide a LangSmith Personal Access Token (PAT) to the api_key argument when instantiating the LangGraph SDK client, or via the X-API-Key header. If using X-API-Key, you must also set the X-Auth-Scheme header to langsmith-api-key. If the PAT you pass is not tied to the owner of the agent, your request will be rejected with a 404 Not Found error. If the agent you’re trying to invoke is a and you’re not the owner, you can perform all the same operations as you would in the UI (read-only).

1. Get the agent ID and URL

To get your agent’s agent_id and api_url:

In the LangSmith UI, navigate to your agent’s inbox.
Next to the agent name, click the Edit Agent icon.
Click the Settings icon in the top right corner.
Click View code snippets to see pre-populated values for your agent.

Copy the code below and replace agent_id and api_url with the values from your agent’s code snippets. Create a .env file in your project root with your Personal Access Token:

.env

LANGGRAPH_API_KEY=your-personal-access-token

2. Fetch agent configuration

Verify your connection by fetching your agent’s configuration:

Python
TypeScript
cURL

import os
from dotenv import load_dotenv
from langgraph_sdk.client import get_client

load_dotenv()

agent_id = "your-agent-id"

api_key = os.getenv("LANGGRAPH_API_KEY")
api_url = "<AGENT-BUILDER-URL>.us.langgraph.app"

client = get_client(
    url=api_url,
    api_key=api_key,
    headers={
        "X-Auth-Scheme": "langsmith-api-key",
    },
)

async def get_assistant(agent_id: str):
    agent = await client.assistants.get(agent_id)
    print(agent)

if __name__ == "__main__":
    import asyncio
    asyncio.run(get_assistant(agent_id))

import "dotenv/config";
import { Client } from "@langchain/langgraph-sdk";

const agentId = "your-agent-id";

const apiKey = process.env.LANGGRAPH_API_KEY;
const apiUrl = "<AGENT-BUILDER-URL>.us.langgraph.app";

const client = new Client({
  apiUrl,
  apiKey,
  defaultHeaders: {
    "X-Auth-Scheme": "langsmith-api-key",
  },
});

async function main(agentId: string) {
  const agent = await client.assistants.get(agentId);
  console.log(agent);
}

main(agentId).catch(console.error);

curl --request GET \
    --url "<AGENT-BUILDER-URL>.us.langgraph.app/assistants/your-agent-id" \
    --header 'Content-Type: application/json' \
    --header 'X-Api-Key: your-personal-access-token' \
    --header 'X-Auth-Scheme: langsmith-api-key'

Use a Personal Access Token (PAT) tied to your LangSmith account. Set the X-Auth-Scheme header to langsmith-api-key for authentication. If you implemented custom authentication, pass the user’s token in headers so the agent can use user-scoped tools. See Add custom authentication.

3. Invoke agent

The examples below show how to send a message to your agent and receive a response. You can use either a stateless run (no thread, no conversation history) or a stateful run (with a thread to maintain conversation history across multiple turns).

Stateless run

A stateless run sends a single request and returns the full response. No conversation history is persisted. This is the simplest way to call your agent:

Python
TypeScript
cURL

import os
from dotenv import load_dotenv
from langgraph_sdk.client import get_client

load_dotenv()

agent_id = "your-agent-id"

api_key = os.getenv("LANGGRAPH_API_KEY")
api_url = "https://<AGENT-BUILDER-URL>.us.langgraph.app"

client = get_client(
    url=api_url,
    api_key=api_key,
    headers={
        "X-Auth-Scheme": "langsmith-api-key",
    },
)

result = await client.runs.wait(
    None,
    agent_id,
    input={
        "messages": [
            {"role": "user", "content": "What can you help me with?"}
        ]
    },
)
print(result)

import "dotenv/config";
import { Client } from "@langchain/langgraph-sdk";

const agentId = "your-agent-id";

const apiKey = process.env.LANGGRAPH_API_KEY;
const apiUrl = "<AGENT-BUILDER-URL>.us.langgraph.app";

const client = new Client({
  apiUrl,
  apiKey,
  defaultHeaders: {
    "X-Auth-Scheme": "langsmith-api-key",
  },
});

const result = await client.runs.wait(
  null,
  agentId,
  {
    input: {
      messages: [
        { role: "user", content: "What can you help me with?" }
      ]
    }
  }
);
console.log(result);

curl --request POST \
    --url "<AGENT-BUILDER-URL>.us.langgraph.app/runs/wait" \
    --header 'Content-Type: application/json' \
    --header 'X-Api-Key: your-personal-access-token' \
    --header 'X-Auth-Scheme: langsmith-api-key' \
    --data '{
        "assistant_id": "your-agent-id",
        "input": {
            "messages": [
                {
                    "role": "user",
                    "content": "What can you help me with?"
                }
            ]
        }
    }'

Stateless streaming run

To stream the response as it is generated rather than waiting for the full result, use the streaming endpoint:

Python
TypeScript
cURL

async for chunk in client.runs.stream(
    None,
    agent_id,
    input={
        "messages": [
            {"role": "user", "content": "What can you help me with?"}
        ]
    },
    stream_mode="updates",
):
    if chunk.data and "run_id" not in chunk.data:
        print(chunk.data)

const streamResponse = client.runs.stream(
  null,
  agentId,
  {
    input: {
      messages: [
        { role: "user", content: "What can you help me with?" }
      ]
    },
    streamMode: "updates"
  }
);
for await (const chunk of streamResponse) {
  if (chunk.data && !("run_id" in chunk.data)) {
    console.log(chunk.data);
  }
}

curl --request POST \
    --url "<AGENT-BUILDER-URL>.us.langgraph.app/runs/stream" \
    --header 'Content-Type: application/json' \
    --header 'X-Api-Key: your-personal-access-token' \
    --header 'X-Auth-Scheme: langsmith-api-key' \
    --data '{
        "assistant_id": "your-agent-id",
        "input": {
            "messages": [
                {
                    "role": "user",
                    "content": "What can you help me with?"
                }
            ]
        },
        "stream_mode": [
            "updates"
        ]
    }'

Stateful run with a thread

To maintain conversation history across multiple interactions, first create a thread and then run your agent on it. Each subsequent run on the same thread has access to the full message history:

Python
TypeScript
cURL

import os
from dotenv import load_dotenv
from langgraph_sdk.client import get_client

load_dotenv()

agent_id = "your-agent-id"

api_key = os.getenv("LANGGRAPH_API_KEY")
api_url = "<AGENT-BUILDER-URL>.us.langgraph.app"

client = get_client(
    url=api_url,
    api_key=api_key,
    headers={
        "X-Auth-Scheme": "langsmith-api-key",
    },
)

thread = await client.threads.create()

async for chunk in client.runs.stream(
    thread["thread_id"],
    agent_id,
    input={
        "messages": [
            {"role": "user", "content": "Hi, my name is Alice."}
        ]
    },
    stream_mode="updates",
):
    if chunk.data and "run_id" not in chunk.data:
        print(chunk.data)

async for chunk in client.runs.stream(
    thread["thread_id"],
    agent_id,
    input={
        "messages": [
            {"role": "user", "content": "What is my name?"}
        ]
    },
    stream_mode="updates",
):
    if chunk.data and "run_id" not in chunk.data:
        print(chunk.data)

import "dotenv/config";
import { Client } from "@langchain/langgraph-sdk";

const agentId = "your-agent-id";

const apiKey = process.env.LANGGRAPH_API_KEY;
const apiUrl = "<AGENT-BUILDER-URL>.us.langgraph.app";

const client = new Client({
  apiUrl,
  apiKey,
  defaultHeaders: {
    "X-Auth-Scheme": "langsmith-api-key",
  },
});

const thread = await client.threads.create();

let streamResponse = client.runs.stream(
  thread["thread_id"],
  agentId,
  {
    input: {
      messages: [
        { role: "user", content: "Hi, my name is Alice." }
      ]
    },
    streamMode: "updates"
  }
);
for await (const chunk of streamResponse) {
  if (chunk.data && !("run_id" in chunk.data)) {
    console.log(chunk.data);
  }
}

streamResponse = client.runs.stream(
  thread["thread_id"],
  agentId,
  {
    input: {
      messages: [
        { role: "user", content: "What is my name?" }
      ]
    },
    streamMode: "updates"
  }
);
for await (const chunk of streamResponse) {
  if (chunk.data && !("run_id" in chunk.data)) {
    console.log(chunk.data);
  }
}

First, create a thread:

curl --request POST \
    --url "<AGENT-BUILDER-URL>.us.langgraph.app/threads" \
    --header 'Content-Type: application/json' \
    --header 'X-Api-Key: your-personal-access-token' \
    --header 'X-Auth-Scheme: langsmith-api-key' \
    --data '{}'

Use the thread_id from the response to send messages on the thread:

curl --request POST \
    --url "<AGENT-BUILDER-URL>.us.langgraph.app/threads/<THREAD_ID>/runs/stream" \
    --header 'Content-Type: application/json' \
    --header 'X-Api-Key: your-personal-access-token' \
    --header 'X-Auth-Scheme: langsmith-api-key' \
    --data '{
        "assistant_id": "your-agent-id",
        "input": {
            "messages": [
                {
                    "role": "user",
                    "content": "Hi, my name is Alice."
                }
            ]
        },
        "stream_mode": [
            "updates"
        ]
    }'

Send a follow-up message on the same thread:

curl --request POST \
    --url "<AGENT-BUILDER-URL>.us.langgraph.app/threads/<THREAD_ID>/runs/stream" \
    --header 'Content-Type: application/json' \
    --header 'X-Api-Key: your-personal-access-token' \
    --header 'X-Auth-Scheme: langsmith-api-key' \
    --data '{
        "assistant_id": "your-agent-id",
        "input": {
            "messages": [
                {
                    "role": "user",
                    "content": "What is my name?"
                }
            ]
        },
        "stream_mode": [
            "updates"
        ]
    }'

REST API reference

The table below summarizes the key endpoints. Replace <API_URL> with your agent’s deployment URL.

Operation	Method	Endpoint
Get agent info	`GET`	`<API_URL>/assistants/<AGENT_ID>`
Create a thread	`POST`	`<API_URL>/threads`
Run (wait for result)	`POST`	`<API_URL>/runs/wait`
Run (streaming)	`POST`	`<API_URL>/runs/stream`
Run on thread (wait)	`POST`	`<API_URL>/threads/<THREAD_ID>/runs/wait`
/langsmith/agent-server-api/thread-runs/create-run-stream-output	`POST`	`<API_URL>/threads/<THREAD_ID>/runs/stream`

All endpoints require the following headers:

Content-Type: application/json
X-Api-Key: your Personal Access Token
X-Auth-Scheme: langsmith-api-key

For the full API specification, see the Agent Server API reference.
